Micro-Drip-Irrigation Terrace Set (30 plants)

Article No. 13400-20

Specifications
Features
Videos
Service & Manuals

Starter set for reliable drip irrigation of up to 30 patio plants

The Micro-Drip-Irrigation Terrace Set from GARDENA is suitable for up to 30 plants and can be used immediately. The Ready-2-Use set contains everything you need for water-saving drip irrigation of individual potted plants on the patio with different water demands or plants in plant troughs and tubs. Setting up the Micro-Drip-System is easy: simply connect it to the tap, lay out the pipes and place the drip heads next to the plants. Everything is clearly explained to you in just a few steps. The MDS components of the set are reusable and therefore sustainable. Discover the patented Quick & Easy connection technique for the 13 mm components and the unique Easy & Flexible connection technique for the 4.6 mm components. You can connect them easily, expand them flexibly and detach them again. The starting module of the Micro-Drip-System is the Master Unit 1000, which regulates the water pressure from the pipe to about 1.5 bar and feeds it evenly into the connected pipes. In addition, thanks to the various drip heads in the set, you have the possibility to individually adjust the water requirements of your plants. The adjustable Endline Drip Heads ensure optimal irrigation of plants with varying or increasing water requirements. You can adjust the water to between 0 and 15 litres per hour. Micro-Drip-System. Caring for your plants and every precious drop. Easy, accurate, water and time-saving irrigation.

Micro-Drip-Irrigation Terrace Set (30 plants)

Technical Specifications

Commercial Reference

13400-20

GTIN-13/EAN

4066407002982

Specifications

Included Components

1 Master Unit 1000, 15 m Connecting Pipe Flex 13 mm (1/2"), 5 Pipe Pegs 13 mm (1/2"), 10 Connectors 13 mm (1/2") - 4.6 mm (3/16"), 2 Plugs 13 mm (1/2"), 20 m Supply Pipe 4.6 mm (3/16"), 20 Pipe Pegs 4.6 mm (3/16"), 5 Plugs 4.6 mm (3/16"), 5 T-Joints 4.6 mm (3/16"), 3 Regulation and Shut-Off Valves 4.6 mm (3/16"), 10 Adjustable Endline Drip Heads 0-15 l/h, 20 Inline Drip Heads 2 l/h, 1 Cleaning Needle

Use

For up to 30 potted plants

Features

1/7

Water-saving drip irrigation set for up to 30 potted plants

The set is ideally suited for water-saving drip irrigation of a total of 30 potted plants with different water requirements on the terrace or plants – both for potted plants and plant rows in troughs or tubs.
2/7

Ready-2-Use and Easy-to-Set

The set is ready for use immediately, as all the necessary components are included. The simple assembly is done in a few easy steps.
3/7

Sustainable thanks to patented Quick & Easy connection technology

All 13 mm components of the set, such as the Connecting Pipes, can be quickly and flexibly rearranged at any time thanks to the patented Quick & Easy connection technology. They are reusable and therefore sustainable. Even after repeated use, they do not get damaged.
4/7

Unique Easy & Flexible connection technology

Thanks to the unique Easy & Flexible connection technology, a quick, easy installation plus the flexible extension of all 4.6 mm components of the Micro-Drip-System set is made possible. All components can be effortlessly connected to each other, flexibly extended or detached.
5/7

For plants in tubs or plant pots with different water requirements

The included Endline Drip Heads are adjustable (0–15 l/h) and therefore ideal for potted plants with different water needs. The Inline Drip Heads are ideal for potted flowers and plants in troughs and can also be adjusted to the water requirement thanks to the included Regulation Valves.
6/7

Flexible expansion

The starter set can be flexibly extended with the GARDENA Micro-Drip components. For even more time-saving and water-saving irrigation, the set can be supplemented with an irrigation controller such as Water Control Flex (Art.-Nr. 1890-20).
7/7

Set contents

The set contains one Master Unit 1000, one 15 m long Connecting Pipe 13 mm (1/2"), one 15 m long Supply Pipe 4.6 mm (3/16"), one Cleaning Needle, two Plugs 13 mm (1/2"), three Shut-Off/Regulation Valves (3/16"), five Peg Pipes (1/2"), five T-Joints 4.6 mm (3/16"), five Plugs 4.6 mm (3/16"), ten T-Joints 13 mm – 4.6 mm, ten adjustable Endline Drip Heads 0–15 l/h, 20 Inline Drip Heads 2 l/h and 20 Peg Pipes (3/16").
